Features:

• MS body with insulation.
• SS drum with perforations & ‘U’ lifters.
• Removable end covers for shaft & bearings.
• Heating by Steam radiator / Thermic fluid radiator / Electrical strip heater.
• Electric motor drive with V-belt system.
• Control panel with timer, buzzer, temp controller.
• Safety interlock limit switch.
• Finish: Enamel paint / optional SS or powder coating.

Models & Specs:

• T.D.25: 25 Kgs capacity, Basket 750x525 mm, 36 RPM speed, ½ HP drive motor, ½ HP blower, 12 KW heater, 20 Kg steam consumption.
• T.D.50: 50 Kgs capacity, Basket 900x900 mm, 36 RPM speed, 1 HP drive motor, 1 HP blower, 18 KW heater, 35 Kg steam consumption.
• T.D.100: 100 Kgs capacity, Basket 1200x970 mm, 36 RPM speed, 2 HP drive motor, 2 HP blower, 24 KW heater, 65 Kg steam consumption.
